Codeur RDS SmartGen 4.1

The SmartGen 4.1 is a fully-functional RDS/RBDS encoder that supports all service IDs and offers simultaneous scrolling-PS, RT messaging and the interactive function RT+ for song tagging. It supports both RDS and RBDS Standards.

UGS : RDS-SG41 Catégorie :

UECP Compatible RDS/RBDS Encoder with LAN & USB Connectivity

Fully-functional, Dynamic RDS/RBDS Encoder
  • Supports European CENELEC and United States NRSC standards
  • Attractive price and very good price-performance ratio
  • Supports RT+ for songs and content tagging
  • PS & Radio Text Scrolling Options
  • Supports TMC (Traffic Message Channel)
  • Compatible with EWS (Emergency Warning System)
  • Embedded WEB server for interactive supervision
  • Fully Digital Synthesis of RDS signal
  • Fully compatible with UECP EBU SPB490 Version 7.05
  • MPX Loopthrough & Sidechain Modes
  • Internal or external Pilot / MPX synchronisation
  • Very Intuitive UECP Configuration Software
  • Remote RDS viewer to visualize broadcasted data



  • Proved and reliable hardware for 24/7/365 operating
  • Easy Installation and Setup
  • LAN & USB Programming Interfaces
  • Remote configuration via ASCII or UECP through LAN or USB
  • Interfaces with all popular radio automation systems
  • Built-in dedicated 19kHz source for internal sync
  • Built-in failsafe bypass relay
  • Includes the TA function for traffic message priority override
  • Works with any FM exciter and stereo generator
  • SNTP for automatic synchronization of the built-in clock
  • Internal data diagnostics and transmission safeguards
  • Real time clock Schedules for Scrolling Text and text lists
  • 19″ Professional Case for high RF immunity

The SmartGen 4.1 is a full-fledged RDS/RBDS encoder that supports both European CENELEC and United States NRSC standards. It supports all service IDs and offers simultaneous scrolling-PS and RadioText messaging. SmartGen 4.1 is fully compatible with the latest UECP EBU SPB490 Version 7.05. The interactive function RT+ for song tagging is fully supported without a compromise. Based on the latest RDS technology, the SmartGen 4.1 is fully digitally designed for 24/7/365 operation. The SmartGen 4.1 is the most cost-effective solution for sending of TMC and EWS Services.

SmartGen 4.1 gives dynamic, on-the-fly programming access with its built-in USB, TCP/IP, UDP/IP interfaces. This connectivity permits full integration of RDS/RBDS transmissions with the station’s other networked functions, including message streaming for digital radio and Webcasting. The SmartGen 4.1 encoder provides a full loopt-hrough interface for connection to your existing broadcast chain. The SmartGen 4.1 can ‘parse’ scrolling text, automatically breaking the phrases into word groups.
